Winnerwell Flashing Kit angled

Product description

Angled Flashing Kit for Tent Walls

Winnerwell Angled Flashing Kit is specially designed for tents with angled walls, such as Winnerwell Teepee Tents. Thanks to its angled design, the chimney pipe can be directed straight up through the tent fabric without needing pipe angles, making the installation both easier and safer. The flashing kit also provides a weather-tight connection at the pipe exit – important for both safety and comfort when using a stove in a tent.

Note! The Angled Flashing Kit must only be used along with pipe insulation/heat protector. It is developed for the Winnerwell Triple-wall Heat Protector Chimney 3.5" and Winnerwell Triple-wall Heat Protector Chimney for External Air M-sized Stove. The silicone collar must never be directly against the flue pipe, as the heat would otherwise become too high and risk damaging the material.

Features

• Angled design: Adapted for tent walls with a slope – the flue pipe can be directed straight up.
• High temperature resistance: The silicone collar withstands up to 240°C and is held in place with AISI304 stainless rings.
• Weather sealing: Protects the tent from rain, wind, and debris at the penetration point.
• Safe installation: Requires an insulated pipe between the chimney pipe and the silicone collar.
• Flexible height adjustment: Use Winnerwell’s short pipe sections to position the collar correctly, below the cooling vents on the insulation pipe.

Specifications

Material:	Silicone collar + AISI304 stainless rings
Top opening diameter:	142 mm
Outer dimensions:	399 × 273 mm
Mounting hole dimensions:	222 × 207 mm
Weight:	1.09 kg

Compatibility

Manufactured for Winnerwell item no. 910446 (our item no. 44952) and 910507 (our item no. 47959). Can also be used with corresponding insulation pipes from other manufacturers or in custom solutions, as long as the pipe penetration has an opening of 142 mm.
